NOAA Sunrise Calculations

Methods for the calculation of sunrise and sunset times based on NOAA methods.

Usage

calcNOAASunrise(
  time.stamp,
  latitude = 0,
  longitude = 0,
  local.hour.offset = 0,
  output = "all"
)

cutDaylight(mydata, latitude = 0, longitude = 0, local.hour.offset = 0)

hour.offset(local, pmatch = TRUE, ignore.case = TRUE)

Arguments

time.stamp: (POSIX) A vector of date/time of POSIX* class.
latitude, longitude: (Numerics) The latitude and longitude of the location where the associated time.stamp measurement was logged. (Note: latitude + to North; - to South. longitude + to East; - to West.)
local.hour.offset: (Numeric or character) The associated local time offset relative to GMT in hours (numeric) or a reference term that hour.offset can convert into a numeric time offset (character). (Note: + to East; - to West).
output: (Character) Either the default "all", which returns all inputs and calculated parameters as a data.frame, or a character vector of field/column names specifying which fields/columns to return. See Value below for summary of calculated parameters generated by this function.
mydata: (Data.frame). A date frame which includes the time.stamp vector as a field/column called date.
local: (Character) The location (or reference) for required hour offset.
pmatch, ignore.case: (Logicals) Supplied local handling. pmatch applies partial (leading edge) matching of reference local terms. ignore.case resets local to upper case before comparing with reference local terms. Both defaults TRUE.

Value

calcNOAASunrise returns a data frame which, depending on the call output value, may include the call arguments and any of the following calculated parameters:

julian.day: (Numeric) The Julian day.
julian.century: (Numeric) The Julian century.
geom.mean.long.sun.deg: (Numeric) The geometric mean longitude of the Sun in degrees.
geom.mean.anom.sun.deg: (Numeric) The geometric mean anomaly of the Sun in degrees.
eccent.earth.orbit: (Numeric) The eccentricity of Earth`s orbit.
sun.eq.of.ctr: (Numeric) The estimated center for the Sun, in degrees.
sun.true.long.deg: (Numeric) The true longitude of the Sun, in degrees.
sun.true.anom.deg: (Numeric) The true anamoly of the Sun, in degrees.
sun.rad.vector.aus: (Numeric) The distance to the Sun, in AUs (radial).
sun.app.long.deg: (Numeric) The apparent longitude of the Sun, in degrees.
mean.obliq.ecliptic.deg: (Numeric) The mean obliquity of the ecliptic, in degrees.
obliq.corr.deg: (Numeric) The corrected obliquity of the ecliptic, in degrees.
sun.rt.ascen.deg: (Numeric) The right ascension of the Sun, in degress.
sun.declin.deg: (Numeric) The declination of the Sun, in degrees.
vary: (Numeric) TO BE CONFIRMED
eq.of.time.minutes: (Numeric) TO BE CONFIRMED
ha.sunrise.deg: (Numeric) TO BE CONFIRMED
solar.noon.lst: (Numeric) TO BE CONFIRMED
sunrise.time.lst: (Numeric) The estimated sunrise time as fraction of day.
sunset.time.lst: (Numeric) The estimated sunset time as fraction of day.
sunlight.duration.minutes: (Numeric) TO BE CONFIRMED
true.solar.time.min: (Numeric) TO BE CONFIRMED
hour.angle.deg: (Numeric) TO BE CONFIRMED
solar.zenith.angle.deg: (Numeric) TO BE CONFIRMED
solar.elevation.angle.deg: (Numeric) TO BE CONFIRMED
approx.atmospheric.refraction.deg: (Numeric) TO BE CONFIRMED
solar.elevation.corrected.for.atm.refraction.deg: (Numeric) TO BE CONFIRMED
solar.azimuth.angle.deg.cw.from.n: (Numeric) TO BE CONFIRMED
daylight: (Factor) A factor specifying if the time.stamp, latitude, longitude and local.hour.offset is estimated to be a daylight or nighttime instance.

cutDaylight is an alternative to calcNOAASunrise which accepts the time stamp as part of a data frame and returns that data frame with the calcNOAACalc output component daylight as an addition field/column.

hour.offset returns the hour.offset as a numeric.

Details

calcNOAASunrise is based on NOAA methods and calculates a range of parameters based on the relative position of the Sun and a receptor point of the Earth`s surface (see value below). The method is valid for dates between 1901 and 2099.cutDaylight is a cut-down version of the same method that was used in the openair package.

hour.offset uses ref.hour.offset as a look-up table to match supplied local terms and return hour.offset values for use in calcNOAASunrise or cutDaylight.

Note

The NOAA Sunrise methods were originally recoded for R as part of work on the NERC penair project: http://www.openair-project.org/. cutDaylight is an alternative version of the function. It is highly similar to code used as part of the function cutData in the package openair to provide daylight conditioning for many plot types within that package.

Character handling for local.hour.offset is by hour.offset and ref.hour.offset.

References

Methods based on: http://www.srrb.noaa.gov/highlights/sunrise/sunrise.html

Author

Karl Ropkins

Examples

#example 1
#calcNOAASunrise
d <- seq(ISOdatetime(2000,1,31,0,0,0), by = "hour", length.out = 24)
ans <- calcNOAASunrise(d)
#solar elevation vs hour of day at (0,0) on 2000-01-31
plot(solar.elevation.corrected.for.atm.refraction.deg~time.stamp,
     main="2000-01-31; latitude 0, longitude 0",
     data=ans, type="b")

#anotate further, add dusk and dawn
#NB: sunrise and sunset are given as fractions of day
dusk <- ISOdatetime(2000,1,31,0,0,0) + (ans$sunset.time.lst*86400)
dawn <- ISOdatetime(2000,1,31,0,0,0) + (ans$sunrise.time.lst*86400)

abline(v=dusk, lty=2)
abline(v=dawn, lty=2)
abline(h=0, lty=3)
arrows(dusk, 25, dusk, 0, col="blue")
text(dusk, 25, "dusk", col="blue")
arrows(dawn, 25, dawn, 0, col="blue")
text(dawn, 25, "dawn", col="blue")
